VAILLANT
THERMOCOMPACT VU 282 E1995-1999 - (08 Connection Parts)
Appliance Code: 41-044-15

Appliance Diagram


08 Connection Parts diagram for Vaillant Thermocompact VU 282 E1995-1999Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 181022, Expansion vessel 12 ltr. EXPANSION VESSEL 12 LTR.
Vaillant part no. 181022
2 Part number 981176, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981176		 £7.92
3 Part number 081088, connection CONNECTION
Vaillant part no. 081088		 £15.42
4 Part number 081666, Connection piece CONNECTION PIECE
Vaillant part no. 081666
5 Part number 126158, spring clamp SPRING CLAMP
Vaillant part no. 126158
6 Part number 981165, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981165		 £6.69
7 Part number 982484, O-ring O-RING
Vaillant part no. 982484
8 Part number 101558, thermo-hydrometer THERMO-HYDROMETER
Vaillant part no. 101558		 £58.64
9 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
10 Part number 981152, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981152		 £7.03
11 Part number 080722, connection Group CONNECTION GROUP
Vaillant part no. 080722
12 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
13 Part number 093897, connection tube CONNECTION TUBE
Vaillant part no. 093897
14 Part number 981158, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981158		 £6.66
15 Part number 190717, pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 190717		 £40.24
16 Part number 105804, cylinder screw CYLINDER SCREW
Vaillant part no. 105804		 £5.13
17 Part number 150232, OBSOLETE by-pass valve OBSOLETE BY-PASS VALVE
Vaillant part no. 150232
18 Part number 981175, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981175
19 Part number 081642, Connection piece CONNECTION PIECE
Vaillant part no. 081642
20 Part number 100376, temperature limiter TEMPERATURE LIMITER
Vaillant part no. 100376		 £25.74
22   CONNECTION TUBE
Vaillant part no. 089265		 £9.69
23 Part number 980960, Gasket GASKET
Vaillant part no. 980960
24 Part number 089062, connection tube CONNECTION TUBE
Vaillant part no. 089062		 £96.31
25 Part number 980765, NOW USE 0020085467 grommet NOW USE 0020085467 GROMMET
Vaillant part no. 980765
25 Part number 0020085467, Gasket GASKET
Vaillant part no. 0020085467		 £6.54
26 Part number 981151, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981151		 £7.86
27 Part number 109914, Plug PLUG
Vaillant part no. 109914		 £17.92
28 Part number 981155, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981155		 £6.34
29 Part number 085751, NOW USE 0020107709 pressure gauge clip NOW USE 0020107709 PRESSURE GAUGE CLIP
Vaillant part no. 085751
29 Part number 0020107709, Support SUPPORT
Vaillant part no. 0020107709		 £6.66
30 Part number 088992, flow switch conduction FLOW SWITCH CONDUCTION
Vaillant part no. 088992		 £7.79
31 Part number 151041, flow switch FLOW SWITCH
Vaillant part no. 151041		 £32.27
32 Part number 126246, OBSOLETE microswitch OBSOLETE MICROSWITCH
Vaillant part no. 126246
33 Part number 154133, NOW USE 0020107697 bow NOW USE 0020107697 BOW
Vaillant part no. 154133
33 Part number 0020107697, Clip CLIP
Vaillant part no. 0020107697		 £6.82
34 Part number 0020107740, SUPPORT SUPPORT
Vaillant part no. 0020107740		 £7.03
34 Part number 085784, NOW USE 0020107740 support NOW USE 0020107740 SUPPORT
Vaillant part no. 085784
35 Part number 161111, pump PUMP
Vaillant part no. 161111		 £182.66
36 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £19.76
37 Part number 118951, Pan head screw, M6x28,5 PAN HEAD SCREW, M6X28,5
Vaillant part no. 118951		 £4.92
38 Part number 118960, Screw - Lens head SCREW - LENS HEAD
Vaillant part no. 118960
44 Part number 202622, NOW USE 0020107716 screw NOW USE 0020107716 SCREW
Vaillant part no. 202622
44 Part number 0020107716, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020107716		 £5.13
47 Part number 135729, service cock SERVICE COCK
Vaillant part no. 135729
48 Part number 135729, service cock SERVICE COCK
Vaillant part no. 135729
49 Part number 154162, NOW USE 0020107702 WIRE CLIP NOW USE 0020107702 WIRE CLIP
Vaillant part no. 154162
49 Part number 0020107702, Clip (PK5) CLIP (PK5)
Vaillant part no. 0020107702		 £6.66
50 Part number 0020107695, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020107695		 £6.66
50 Part number 235715, NOW USE 0020107695 Tapping screw ISO 7049 NOW USE 0020107695 TAPPING SCREW ISO 7049
Vaillant part no. 235715
51 Part number 140015, Screw - De-aeration SCREW - DE-AERATION
Vaillant part no. 140015		 £6.66
52 Part number 981166, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981166		 £6.66
53 Part number 981146, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981146		 £6.69
54   PLUG
Vaillant part no. 139451		 £5.17
55 Part number 950017, Cap CAP
Vaillant part no. 950017		 £6.66
56 Part number 087992, Connection piece CONNECTION PIECE
Vaillant part no. 087992
