VOKERA
MYNUTE 35 HE SYSTEM REV 9 (11/09) - (Hydraulics 1)
Appliance Code: 41-094-64

Appliance Diagram


Hydraulics 1 diagram for Vokera Mynute 35 HE System Rev 9 (11/09)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

3 Part number 10028141, NOW USE 20003181 Water Pressure switch NOW USE 20003181 WATER PRESSURE SWITCH
Vokera part no. 10028141

3 Part number 20003181, Water pressure switch - Replaced 10028141 WATER PRESSURE SWITCH - REPLACED 10028141
Vokera part no. 20003181
£9.83
7 Part number 1552, Valve For DHW Bypass VALVE FOR DHW BYPASS
Vokera part no. 1552
£7.77
9 Part number 10028415, Heating manifold HEATING MANIFOLD
Vokera part no. 10028415
£78.52
22 Part number 2907, Safety valve Replaced 8433 (Push Fit) SAFETY VALVE REPLACED 8433 (PUSH FIT)
Vokera part no. 2907
£14.33
27 Part number 10029757, Heating Cock 28mm HEATING COCK 28MM
Vokera part no. 10029757
£38.00
31 Part number 01005137, Venting Plugs Kit VENTING PLUGS KIT
Vokera part no. 01005137
£9.76
63 Part number 10020898, Safety Valve Outlet Tail SAFETY VALVE OUTLET TAIL
Vokera part no. 10020898
£11.05
200 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023
£0.43
265 Part number 5236, Washer WASHER
Vokera part no. 5236
£0.69
266 Part number 5237, Washer 28mm WASHER 28MM
Vokera part no. 5237
£0.88
288 Part number 6898, O Ring O RING
Vokera part no. 6898
£1.03
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.77
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

432 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958
£0.98
