VOKERA
COMPACT 25 HE NG - (Combustion Fan Components)
Appliance Code: 47-094-73

Appliance Diagram


Combustion  Fan Components diagram for Vokera Compact 25 HE NGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 10025935, Combustion chamber COMBUSTION CHAMBER
Vokera part no. 10025935
£16.15
2 Part number 5270, Rear Insulation Panel for Combustion Chamber REAR INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5270
£18.05
3 Part number 5271, Side Insulation Panel for Combustion Chamber SIDE INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5271
£9.50
4 Part number 5269, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5269
£17.10
7   FLUE HOOD ASSEMBLY
Vokera part no. 10024310
£22.80
10 Part number 10024035, Fan FAN
Vokera part no. 10024035
£182.40
13 Part number 01005405, NOW USE 20030209 Venturi/pressure tube kit NOW USE 20030209 VENTURI/PRESSURE TUBE KIT
Vokera part no. 01005405

13 Part number 20030209, Venturi kit (Repl 01005405) VENTURI KIT (REPL 01005405)
Vokera part no. 20030209
£24.70
16 Part number 10024126, Clamp CLAMP
Vokera part no. 10024126
£19.95
19 Part number 10024137, Fan flue connection FAN FLUE CONNECTION
Vokera part no. 10024137
£38.95
20 Part number 10026933, Block with combustion analysis check BLOCK WITH COMBUSTION ANALYSIS CHECK
Vokera part no. 10026933
£9.50
23 Part number 8086, Brass Cap BRASS CAP
Vokera part no. 8086
£2.57
25 Part number 10020889, Air Pressure Switch AIR PRESSURE SWITCH
Vokera part no. 10020889
£43.70
100 Part number 10027559, CN4 to Fan & CN8 to Heat Thermistor, PD switch & high limit stat wiring CN4 TO FAN & CN8 TO HEAT THERMISTOR, PD SWITCH & HIGH LIMIT STAT WIRING
Vokera part no. 10027559
£55.10
