KESTON
KESTON K60 NG - (Casing)
Appliance Code: 41-930-02

Appliance Diagram


Casing diagram for Keston Keston K60 NGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE K50&60 CABINET (EXC.FRONT DOOR)
Keston part no. B04103000
2 Part number B04100491, 28mm GROMMET (FROM SN 2200) 28MM GROMMET (FROM SN 2200)
Keston part no. B04100491		 £4.69
3   AIR FILTER TRAY- LARGE (FROM SN 2040)
Keston part no. B04114001		 £78.93
4 Part number B04100400, M4x10 SCREW - cross recessed pan head M4X10 SCREW - CROSS RECESSED PAN HEAD
Keston part no. B04100400		 £2.10
5   OBSOLETE CASE TOP COVER - LARGE FILTER (FROM SN 2040)
Keston part no. B04109001
6   OBSOLETE BURNER ACCESS COVER
Keston part no. B04100320
7 Part number B04100410, M3x6 SCREW - cross recessed pan head M3X6 SCREW - CROSS RECESSED PAN HEAD
Keston part no. B04100410		 £0.33
9 Part number B04100370, FRONT DOOR SCREW FRONT DOOR SCREW
Keston part no. B04100370		 £2.99
10 Part number B04100420, M5 NUT -hexagon M5 NUT -HEXAGON
Keston part no. B04100420		 £2.32
11 Part number B04100430, A5 WASHER - plain A5 WASHER - PLAIN
Keston part no. B04100430		 £2.21
12   OBSOLETE K80 FRONT DOOR
Keston part no. B08113000
14 Part number B04120001, SILENCER SILENCER
Keston part no. B04120001		 £14.99
16 Part number B04100390, M6 NUT - hexagon M6 NUT - HEXAGON
Keston part no. B04100390		 £2.47
17   BLOWER PLATE
Keston part no. B04100360		 £50.77
19   BRACKET (WALL MOUNTING)
Keston part no. B04100350		 £9.79
20   OBSOLETE K50 DATA PLATE
Keston part no. B05100500
21 Part number B04100760, OBSOLETE M6x8 SCREW - hexagon socket head cap OBSOLETE M6X8 SCREW - HEXAGON SOCKET HEAD CAP
Keston part no. B04100760
22 Part number B17112000, AIR FILTER - large (FROM SN 2040) AIR FILTER - LARGE (FROM SN 2040)
Keston part no. B17112000		 £31.88
23   OBSOLETE AIR INLET LABEL
Keston part no. B04100510
24   OBSOLETE EXHAUST FLUE LABEL
Keston part no. B04100520
25   OBSOLETE FLOW LABEL
Keston part no. B04100530
26 Part number B04100470, 42mm GROMMET 42MM GROMMET
Keston part no. B04100470		 £6.31
27 Part number B04100490, 22mm GROMMET 22MM GROMMET
Keston part no. B04100490		 £4.69
28   OBSOLETE RETURN LABEL
Keston part no. B04100540
29   OBSOLETE WARNING LABEL
Keston part no. B04100550
30   OBSOLETE ILLUST. WIRING DIAGRAM RAM (FROM SN 2357)
Keston part no. B04100561
33 Part number B04116000, ELEC.MAIN WIRE RETAINER-Replaces B34400120 ELEC.MAIN WIRE RETAINER-REPLACES B34400120
Keston part no. B04116000		 £2.48
34   TEST POINT LABEL
Keston part no. B04100580		 £2.02
35   OBSOLETE GAS INLET LABEL
Keston part no. B04100590
37   CABLE TIE BASE
Keston part no. B04100850		 £1.00
40 Part number B04130000, OBSOLETE EXHAUST TERMINAL OBSOLETE EXHAUST TERMINAL
Keston part no. B04130000
41 Part number B04118000, OBSOLETE GAS TAP - 15mm OBSOLETE GAS TAP - 15MM
Keston part no. B04118000
42   OBSOLETE N5 EARTHING LOCK WASHER
Keston part no. B04100450
65 Part number B17100032, SPRING CLAMP SPRING CLAMP
Keston part no. B17100032		 £7.97
