VAILLANT
THERMO COMPACT VC 221 T1988-1996 - (07 Casing Parts)
Appliance Code: 41-044-05

Appliance Diagram


07 Casing Parts diagram for Vaillant Thermo Compact VC 221 T1988-1996Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2 Part number 208816, OBSOLETE support OBSOLETE SUPPORT
Vaillant part no. 208816
3 Part number 116462, Hexagon screw, M8x25 HEXAGON SCREW, M8X25
Vaillant part no. 116462		 £6.66
4 Part number 114838, Hexagonal nut G 3/4 HEXAGONAL NUT G 3/4
Vaillant part no. 114838
5   BOW
Vaillant part no. 154227		 £12.72
6 Part number 070350, screw SCREW
Vaillant part no. 070350		 £3.91
7   DISC
Vaillant part no. 060020		 £3.91
8   PACKING RING
Vaillant part no. 980093		 £3.91
9   OBSOLETE NUT
Vaillant part no. 070357
10   SCREW
Vaillant part no. 235737		 £3.91
11   SUPPORT
Vaillant part no. 149628		 £7.37
12 Part number 235727, screw SCREW
Vaillant part no. 235727		 £5.13
15   OBSOLETE COVER PLATE
Vaillant part no. 070886
17 Part number 235738, Tapping screw TAPPING SCREW
Vaillant part no. 235738
18 Part number 492032, Washer WASHER
Vaillant part no. 492032		 £5.63
19   OBSOLETE FLUE EXTENSION DUCT
Vaillant part no. 145578
20   OBSOLETE FRONT PANEL
Vaillant part no. 078262
22 Part number 078274, OBSOLETE front panel OBSOLETE FRONT PANEL
Vaillant part no. 078274
23 Part number 282249, INSPECTION WINDOW RING INSPECTION WINDOW RING
Vaillant part no. 282249		 £3.91
24 Part number 981746, packing ring PACKING RING
Vaillant part no. 981746		 £3.91
25 Part number 161225, OBSOLETE Inspection glass OBSOLETE INSPECTION GLASS
Vaillant part no. 161225
26 Part number 235748, Tapping screw ISO 7049 TAPPING SCREW ISO 7049
Vaillant part no. 235748		 £5.13
28 Part number 980766, NOW USE 0010027618 seal NOW USE 0010027618 SEAL
Vaillant part no. 980766
28   GASKET, (X5)
Vaillant part no. 0010027618		 £5.80
29   OBSOLETE CAP
Vaillant part no. 178427
30 Part number 079921, side panel, left SIDE PANEL, LEFT
Vaillant part no. 079921		 £24.68
31 Part number 079920, side panel, right SIDE PANEL, RIGHT
Vaillant part no. 079920		 £32.54
32 Part number 088620, Fastening set FASTENING SET
Vaillant part no. 088620
33 Part number 070351, HINGE PIN HINGE PIN
Vaillant part no. 070351		 £3.91
36 Part number 158207, snap nut SNAP NUT
Vaillant part no. 158207		 £3.91
38 Part number 294013, bottom door panel BOTTOM DOOR PANEL
Vaillant part no. 294013		 £28.05
39 Part number 124870, BUSH BUSH
Vaillant part no. 124870		 £3.91
40 Part number 075461, covering plate COVERING PLATE
Vaillant part no. 075461		 £15.31
