VAILLANT
ECOCRAFT SYSTEM VKK 2406/2-E 2006-2009 - (06 Heat Exchanger)
Appliance Code: VKK 2406/2-E

Appliance Diagram


06 Heat Exchanger diagram for Vaillant Ecocraft System VKK 2406/2-E 2006-2009Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 090746, Ignition electrode IGNITION ELECTRODE
Vaillant part no. 090746		 £30.57
2 Part number 090743, Electrode (monitoring) ELECTRODE (MONITORING)
Vaillant part no. 090743		 £29.58
3 Part number 981391, Gasket (PK4) GASKET (PK4)
Vaillant part no. 981391		 £11.90
4 Part number 091558, ignition cable IGNITION CABLE
Vaillant part no. 091558		 £70.43
5 Part number 161271, Inspection glass INSPECTION GLASS
Vaillant part no. 161271		 £34.97
6 Part number 101767, Thermostat (PK4) THERMOSTAT (PK4)
Vaillant part no. 101767		 £55.60
7 Part number 290809, Clip NTC/STB (PK5) CLIP NTC/STB (PK5)
Vaillant part no. 290809		 £59.56
8 Part number 0020019838, sensor SENSOR
Vaillant part no. 0020019838		 £30.57
10 Part number 219626, Clip (PK8) CLIP (PK8)
Vaillant part no. 219626		 £9.49
10   INSULATION
Vaillant part no. 177724		 £261.41
10   INSULATION
Vaillant part no. 177725		 £214.69
10   INSULATION
Vaillant part no. 177726		 £268.02
10   INSULATION
Vaillant part no. 177727		 £305.81
10   INSULATION
Vaillant part no. 177728		 £421.68
10   INSULATION 280
Vaillant part no. 177729		 £391.55
11 Part number 138807, Screw (PK5) SCREW (PK5)
Vaillant part no. 138807		 £46.32
11   BUSH
Vaillant part no. 0020037751		 £13.29
12 Part number 981277, Sealing ring (PK16) SEALING RING (PK16)
Vaillant part no. 981277		 £15.62
13 Part number 712152, Sensor NTC (PK10) SENSOR NTC (PK10)
Vaillant part no. 712152		 £166.81
14 Part number 280295, Clip NTC-sensor (PK5) CLIP NTC-SENSOR (PK5)
Vaillant part no. 280295		 £62.55
15 Part number 061723, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061723		 £42.17
16 Part number 050591, pressure safeguard PRESSURE SAFEGUARD
Vaillant part no. 050591		 £34.97
17 Part number 082252, Drain cock DRAIN COCK
Vaillant part no. 082252		 £38.90
18 Part number 981301, Gasket (PK10) GASKET (PK10)
Vaillant part no. 981301		 £153.32
19 Part number 153044, filter FILTER
Vaillant part no. 153044		 £38.14
20 Part number 0020019839, Gasket kit GASKET KIT
Vaillant part no. 0020019839		 £38.14
21   COLLECTING SHEET 80KW
Vaillant part no. 0020019820		 £843.02
21   COLLECTING SHEET 120KW
Vaillant part no. 0020019821		 £918.34
21 Part number 0020019822, Collecting sheet 160kW COLLECTING SHEET 160KW
Vaillant part no. 0020019822		 £903.58
21   COLLECTING SHEET 280KW
Vaillant part no. 0020019825		 £1,201.51
21 Part number 0020019823, Collecting sheet 200kW COLLECTING SHEET 200KW
Vaillant part no. 0020019823		 £1,029.65
21   COLLECTING SHEET 240KW
Vaillant part no. 0020019824		 £1,119.64
22   GASKET (COLLECTING SHEET ) 240 KW
Vaillant part no. 0020019814		 £52.07
22 Part number 0020019815, Gasket (collecting sheet ) 280 kW GASKET (COLLECTING SHEET ) 280 KW
Vaillant part no. 0020019815		 £43.86
22 Part number 0020019810, Gasket (collecting sheet ) 80 kW GASKET (COLLECTING SHEET ) 80 KW
Vaillant part no. 0020019810
22 Part number 0020019811, Gasket (collecting sheet ) 120 kW GASKET (COLLECTING SHEET ) 120 KW
Vaillant part no. 0020019811		 £38.90
22 Part number 0020019812, Gasket (collecting sheet ) 160 kW GASKET (COLLECTING SHEET ) 160 KW
Vaillant part no. 0020019812		 £42.17
22 Part number 0020019813, Gasket (collecting sheet ) 200 kW GASKET (COLLECTING SHEET ) 200 KW
Vaillant part no. 0020019813		 £46.32
23 Part number 0020019817, cover COVER
Vaillant part no. 0020019817		 £55.60
24 Part number 0020019816, Gasket, cover condensate GASKET, COVER CONDENSATE
Vaillant part no. 0020019816		 £17.92
25 Part number 0020019835, Flue duct 80-160 kW FLUE DUCT 80-160 KW
Vaillant part no. 0020019835		 £349.87
25   FLUE DUCT 200-280 KW
Vaillant part no. 0020019836		 £343.00
26   CAP (PK5)
Vaillant part no. 255651		 £166.81
27 Part number 981383, Gasket (D 155.3) GASKET (D 155.3)
Vaillant part no. 981383		 £14.45
27 Part number 981384, Gasket (D 205.3) GASKET (D 205.3)
Vaillant part no. 981384		 £15.62
28 Part number 0020019837, Gasket GASKET
Vaillant part no. 0020019837		 £27.34
29   CONDENSING DRAIN
Vaillant part no. 011538		 £24.60
