VAILLANT
ECOMAX 635 E VU356-C 2004-2008 - (12 Control Box)
Appliance Code: 41-044-43

Appliance Diagram


12 Control Box diagram for Vaillant Ecomax 635 E VU356-C 2004-2008Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 098912, support SUPPORT
Vaillant part no. 098912
£8.28
1 Part number 295248, casing CASING
Vaillant part no. 295248
£94.40
2 Part number 251957, Fuse T4H (PK10) FUSE T4H (PK10)
Vaillant part no. 251957
£7.05
3 Part number 114288, Knobs, grey, kit of 3 KNOBS, GREY, KIT OF 3
Vaillant part no. 114288
£11.36
4 Part number 130826, Printed circuit board PRINTED CIRCUIT BOARD
Vaillant part no. 130826
£275.69
5 Part number 130822, printed circuit with display (grey) PRINTED CIRCUIT WITH DISPLAY (GREY)
Vaillant part no. 130822
£45.01
6 Part number 101271, Pressure gauge PRESSURE GAUGE
Vaillant part no. 101271
£38.09
6A Part number 0020107709, Support SUPPORT
Vaillant part no. 0020107709
£6.66
6A Part number 085751, NOW USE 0020107709 pressure gauge clip NOW USE 0020107709 PRESSURE GAUGE CLIP
Vaillant part no. 085751

6B Part number 981155, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981155
£6.34
7 Part number 509127, cable tree CABLE TREE
Vaillant part no. 509127

8 Part number 078533, cable fixation CABLE FIXATION
Vaillant part no. 078533
£8.31
9 Part number 078536, Cable fixing, kit of 2 CABLE FIXING, KIT OF 2
Vaillant part no. 078536
£6.66
