POTTERTON
PERFORMA 28I - (Hydraulics)
Appliance Code: 47-393-08

Appliance Diagram


Hydraulics diagram for Potterton Performa 28IClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

70 Part number 248040, PIPE ASSEMBLY - RETURN - 105 PIPE ASSEMBLY - RETURN - 105
Potterton part no. 248040		 £14.70
71 Part number 248193, CLIP - PLASTIC CLIP - PLASTIC
Potterton part no. 248193		 £3.26
72 Part number 7722642, PUMP 15-60 105 PUMP 15-60 105
Potterton part no. 7722642		 £254.27
72 Part number 248042, NOW USE 7722642 PUMP (15-60) - 105 NOW USE 7722642 PUMP (15-60) - 105
Potterton part no. 248042
73 Part number 248043, AIR VENT - AUTOMATIC AIR VENT - AUTOMATIC
Potterton part no. 248043		 £12.50
74 Part number 248044, O-RING - AIR VENT O-RING - AIR VENT
Potterton part no. 248044		 £3.16
75 Part number 248045, GROMMET - PIPE ASSEMBLY GROMMET - PIPE ASSEMBLY
Potterton part no. 248045		 £5.88
77 Part number 248049, GASKET - PLATE HEAT EXCHANGER GASKET - PLATE HEAT EXCHANGER
Potterton part no. 248049		 £5.78
80 Part number 248246, HYDRAULIC INLET ASSEMBLY - 105 HYDRAULIC INLET ASSEMBLY - 105
Potterton part no. 248246		 £116.43
82 Part number 248051, HYDRAULIC VENTURI ASSEMBLY HYDRAULIC VENTURI ASSEMBLY
Potterton part no. 248051		 £14.98
84 Part number 248052, FILTER - DHW FILTER - DHW
Potterton part no. 248052		 £5.88
85 Part number 248053, O RING VENTURI ASSEMBLY O RING VENTURI ASSEMBLY
Potterton part no. 248053		 £4.57
86 Part number 247429, O RING 22mm X 3mm O RING 22MM X 3MM
Potterton part no. 247429		 £3.16
87 Part number 248054, PUMP CONNECTION ELEMENT PUMP CONNECTION ELEMENT
Potterton part no. 248054		 £6.31
88 Part number 237473, FLOW REGULATOR 12L - RED FLOW REGULATOR 12L - RED
Potterton part no. 237473		 £18.24
89 Part number 248000, WASHER - SEALING WASHER - SEALING
Potterton part no. 248000		 £3.16
91 Part number 248055, DRAIN TAP DRAIN TAP
Potterton part no. 248055		 £9.88
92 Part number 248056, SAFETY VALVE - 3 BAR (FEMALE) SAFETY VALVE - 3 BAR (FEMALE)
Potterton part no. 248056		 £14.76
96 Part number 248724, PIPE-POSITIVE PRESSURE PIPE-POSITIVE PRESSURE
Potterton part no. 248724		 £10.03
97 Part number 248725, PIPE-NEGATIVE PRESSURE PIPE-NEGATIVE PRESSURE
Potterton part no. 248725		 £10.03
98 Part number 248726, PIPE ASSEMBLY-BYPASS PIPE ASSEMBLY-BYPASS
Potterton part no. 248726		 £24.47
99 Part number 248060, CLIP FIXING - BYPASS CLIP FIXING - BYPASS
Potterton part no. 248060		 £5.88
101 Part number 248018, O RING O RING
Potterton part no. 248018		 £3.20
101 Part number 248619, DIAPHRAGM-PRESSURE-STAT DIAPHRAGM-PRESSURE-STAT
Potterton part no. 248619		 £10.78
102 Part number 248727, VALVE-3 WAY ASSEMBLY VALVE-3 WAY ASSEMBLY
Potterton part no. 248727		 £138.62
103 Part number 248728, PRESSURE DIFFERENTIAL ASSEMBLY PRESSURE DIFFERENTIAL ASSEMBLY
Potterton part no. 248728		 £91.46
128 Part number 248020, O RING O RING
Potterton part no. 248020		 £3.26
131 Part number 247394, NOW USE 5108265 TEMPERATURE SENSOR NOW USE 5108265 TEMPERATURE SENSOR
Potterton part no. 247394
131 Part number 5108265, TEMPERATURE SENSOR TEMPERATURE SENSOR
Potterton part no. 5108265		 £20.07
132 Part number 248069, GASKET GASKET
Potterton part no. 248069		 £3.34
135 Part number 248078, NOW USE 5115349 THERMOSTAT LIMIT 80Eco NOW USE 5115349 THERMOSTAT LIMIT 80ECO
Potterton part no. 248078
135 Part number 248079, THERMOSTAT - LIMIT THERMOSTAT - LIMIT
Potterton part no. 248079		 £12.56
135 Part number 5115349, OVERHEAT STAT KIT OVERHEAT STAT KIT
Potterton part no. 5115349		 £21.36
136 Part number 248729, PIPE-FLOW-INSTANT PIPE-FLOW-INSTANT
Potterton part no. 248729		 £19.05
137 Part number 248082, ELBOW - GAS FLOW OUTLET ELBOW - GAS FLOW OUTLET
Potterton part no. 248082		 £6.96
138 Part number 247741, O RING 22.22 x 2.62 O RING 22.22 X 2.62
Potterton part no. 247741		 £3.16
139 Part number 248083, CONNECTOR - GAS VALVE INLET CONNECTOR - GAS VALVE INLET
Potterton part no. 248083		 £9.51
140 Part number 248085, NOW USE 5107339 GAS VALVE VK4105A NOW USE 5107339 GAS VALVE VK4105A
Potterton part no. 248085
140 Part number 5107339, GAS VALVE ASSY INC O-RINGS GAS VALVE ASSY INC O-RINGS
Potterton part no. 5107339		 £173.39
141 Part number 248086, MODULATION COIL AND SPRING MODULATION COIL AND SPRING
Potterton part no. 248086		 £12.55
145 Part number 247776, CLAMP - INPUT CABLE CLAMP - INPUT CABLE
Potterton part no. 247776		 £4.38
147 Part number 248087, PANEL - HYDRAULICS MOUNTING PANEL - HYDRAULICS MOUNTING
Potterton part no. 248087		 £12.25
192 Part number 247745, SEALING WASHER G. 3/4 SEALING WASHER G. 3/4
Potterton part no. 247745		 £3.16
316 Part number 247757, CLIP-MICROSWITCH RETAINING CLIP-MICROSWITCH RETAINING
Potterton part no. 247757		 £3.26
387 Part number 248733, NOW USE 7216534 MOTOR 3 WAY VALVE NOW USE 7216534 MOTOR 3 WAY VALVE
Potterton part no. 248733
387 Part number 5132452, NOW USE 7216534 SPARES KIT MOTOR ELBI (B/W) NOW USE 7216534 SPARES KIT MOTOR ELBI (B/W)
Potterton part no. 5132452
387 Part number 710188301, NOW USE 7216534 MOTOR (black/white) NOW USE 7216534 MOTOR (BLACK/WHITE)
Potterton part no. 710188301
387 Part number 7216534, MOTOR BLACK/WHITE INC CLIP MOTOR BLACK/WHITE INC CLIP
Potterton part no. 7216534		 £46.67
390 Part number 248734, VALVE-DIFFERENTIAL-DHW VALVE-DIFFERENTIAL-DHW
Potterton part no. 248734		 £72.74
391 Part number 248735, WASHER-SEALING-4x8x1.5 WASHER-SEALING-4X8X1.5
Potterton part no. 248735		 £3.26
392 Part number 248736, CLIP-RETAINING CLIP-RETAINING
Potterton part no. 248736		 £4.57
394 Part number 248838, DIAPHRAGM-DHW/DIFF-INSTANT DIAPHRAGM-DHW/DIFF-INSTANT
Potterton part no. 248838		 £10.53
487 Part number 248738, PIPE-EXPANSION VESSEL INLET PIPE-EXPANSION VESSEL INLET
Potterton part no. 248738		 £11.95
488 Part number 248739, PIPE-EXPANSION VESSEL OUTLET PIPE-EXPANSION VESSEL OUTLET
Potterton part no. 248739
