VOKERA
LINEA PLUS AG - (Hydraulics 1)
Appliance Code: 47-094-31

Appliance Diagram


Hydraulics 1 diagram for Vokera Linea Plus AGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 2573, Expansion Vessel Rep 106333 10 Litre EXPANSION VESSEL REP 106333 10 LITRE
Vokera part no. 2573
£104.11
2 Part number 10023603, Flexible Expansion Pipe FLEXIBLE EXPANSION PIPE
Vokera part no. 10023603
£21.23
3 Part number 10020439, Heating manifold HEATING MANIFOLD
Vokera part no. 10020439
£79.58
4   PIPE
Vokera part no. 10023211
£16.98
5 Part number 10022349, DHW Actuator replaces 10020330 DHW ACTUATOR REPLACES 10020330
Vokera part no. 10022349
£33.95
6 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.77
6 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

7 Part number 10023567, C-Water inlet valve/Stop Cock - Screws into non return valve C-WATER INLET VALVE/STOP COCK - SCREWS INTO NON RETURN VALVE
Vokera part no. 10023567
£32.55
8 Part number 10023570, Flexible Pipe/Filling Loop FLEXIBLE PIPE/FILLING LOOP
Vokera part no. 10023570
£24.49
9 Part number 10023569, Non-Return/Double-Check Valve NON-RETURN/DOUBLE-CHECK VALVE
Vokera part no. 10023569
£22.61
10 Part number 1790, Connection Rep 088128 CONNECTION REP 088128
Vokera part no. 1790
£15.87
11 Part number 10023566, Heating Flow Cock/Service Valve HEATING FLOW COCK/SERVICE VALVE
Vokera part no. 10023566
£33.01
12 Part number 1789, Heating Cock 22mm (Washers are 5237) HEATING COCK 22MM (WASHERS ARE 5237)
Vokera part no. 1789
£24.62
13 Part number 10023643, S.Valve outlet tail repl 1792 S.VALVE OUTLET TAIL REPL 1792
Vokera part no. 10023643
£18.87
14 Part number 1793, Brass Nut Rep 088131` BRASS NUT REP 088131`
Vokera part no. 1793
£7.27
16 Part number 1749, Water Stop Cock WATER STOP COCK
Vokera part no. 1749
£25.78
17 Part number 10023568, Supply Inlet Valve SUPPLY INLET VALVE
Vokera part no. 10023568
£22.94
22 Part number 5208, Washer WASHER
Vokera part no. 5208
£0.21
23 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026
£0.39
26 Part number 5236, Washer WASHER
Vokera part no. 5236
£0.69
27 Part number 5237, Washer 28mm WASHER 28MM
Vokera part no. 5237
£0.88
28 Part number 1820, Clip CLIP
Vokera part no. 1820
£0.94
30 Part number 1824, Nut (Large) NUT (LARGE)
Vokera part no. 1824
£1.60
32 Part number 1823, Nut (Small) NUT (SMALL)
Vokera part no. 1823
£1.60
