GLOWWORM
ULTRAPOWER 100SXI - (PCB/Controls)
Appliance Code: 41-019-09

Appliance Diagram


PCB/Controls diagram for Glowworm Ultrapower 100SXIClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

73 Part number 0020018811, NOW USE S1042400 seal (set of 5) NOW USE S1042400 SEAL (SET OF 5)
Glowworm part no. 0020018811
73 Part number S1042400, Gasket electrode (PK5) GASKET ELECTRODE (PK5)
Glowworm part no. S1042400		 £20.71
74 Part number 0020018810, electrode+ screw + gasket ELECTRODE+ SCREW + GASKET
Glowworm part no. 0020018810		 £27.49
102 Part number 0020014161, automatic air vent AUTOMATIC AIR VENT
Glowworm part no. 0020014161		 £21.92
103 Part number 0020020781, NOW USE S5739800 temperature monitor NOW USE S5739800 TEMPERATURE MONITOR
Glowworm part no. 0020020781
103 Part number 2000801935, NOW USE S5739800 ntc with clip d=18mm 10kOhm NOW USE S5739800 NTC WITH CLIP D=18MM 10KOHM
Glowworm part no. 2000801935
103 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800		 £23.87
104 Part number 0020020780, cable tree (zig harness) CABLE TREE (ZIG HARNESS)
Glowworm part no. 0020020780		 £14.81
107 Part number 0020020763, igniter IGNITER
Glowworm part no. 0020020763		 £28.53
108 Part number SK7959, Screw, M3x6mm SCREW, M3X6MM
Glowworm part no. SK7959		 £6.61
109 Part number 0020038062, Casing CASING
Glowworm part no. 0020038062		 £25.46
110 Part number 0020038061, display DISPLAY
Glowworm part no. 0020038061		 £185.69
111 Part number 0020037668, printed circuit PRINTED CIRCUIT
Glowworm part no. 0020037668		 £294.80
112 Part number 0020025183, appliance interface harness APPLIANCE INTERFACE HARNESS
Glowworm part no. 0020025183		 £13.27
113   BACK PANEL
Glowworm part no. 0020038063		 £12.93
114 Part number 0020026405, NOW USE 0020079603 fuse NOW USE 0020079603 FUSE
Glowworm part no. 0020026405
114 Part number 0020079603, Fuse 2,0 A T2H (PK10) FUSE 2,0 A T2H (PK10)
Glowworm part no. 0020079603		 £14.09
115 Part number 0020038263, fitting FITTING
Glowworm part no. 0020038263		 £6.61
117 Part number 0020038266, cable tree (harness) CABLE TREE (HARNESS)
Glowworm part no. 0020038266		 £46.70
118 Part number 0020038267, cable tree (harness) CABLE TREE (HARNESS)
Glowworm part no. 0020038267		 £46.70
131 Part number 802256, IGNITION LEAD IGNITION LEAD
Glowworm part no. 802256		 £20.45
132 Part number 0020038260, Gasket GASKET
Glowworm part no. 0020038260		 £18.55
133 Part number 0020038262, Box BOX
Glowworm part no. 0020038262		 £33.89
134 Part number 0020038262, Box BOX
Glowworm part no. 0020038262		 £33.89
135 Part number 0020014188, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020014188		 £6.61
136   TOOTHED WASHER
Glowworm part no. 0020038265		 £6.61
