WORCESTER
GREENSTAR 40 CDI CONVENTIONAL - (Tubes & Connections)
Appliance Code: 41-311-72

Appliance Diagram


Tubes & Connections diagram for Worcester Greenstar 40 CDI ConventionalClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 87105062540, NOW USE 87182256360 SIPHON NOW USE 87182256360 SIPHON
Worcester part no. 87105062540

1 Part number 87182256360, SIPHON SIPHON
Worcester part no. 87182256360
£83.86
2 Part number 87154051890, PROTECTIVE CAP PROTECTIVE CAP
Worcester part no. 87154051890
£6.55
3   COVER
Worcester part no. 87154051880
£6.55
4   CORRUGATED PIPE
Worcester part no. 87377026640
£18.04
5 Part number 87107032200, HOSE HOSE
Worcester part no. 87107032200
£3.13
6 Part number 87102050970, SET OF O-RINGS SET OF O-RINGS
Worcester part no. 87102050970
£9.24
7 Part number 87186846990, CLIP WIRE 18mm (10X) CLIP WIRE 18MM (10X)
Worcester part no. 87186846990
£2.78
8   FLOW PIPE
Worcester part no. 87107353580
£98.28
9 Part number 87161405000, AIR-VENT AUTOMATIC 3/8 (SS KIT) AIR-VENT AUTOMATIC 3/8 (SS KIT)
Worcester part no. 87161405000
£11.25
10 Part number 87101030460, WASHER 1" (10X) WASHER 1" (10X)
Worcester part no. 87101030460
£2.95
10 Part number 87161156820, WASHER 1" (1X) WASHER 1" (1X)
Worcester part no. 87161156820
£2.95
11 Part number 87107353590, FLOW PIPE FLOW PIPE
Worcester part no. 87107353590
£51.42
12   RETURN PIPE
Worcester part no. 87107353610
£71.21
13   RETURN PIPE
Worcester part no. 87107353600
£49.28
14 Part number 87167711540, O-RING 17X4 (10X) AFTER FD992 O-RING 17X4 (10X) AFTER FD992
Worcester part no. 87167711540
£2.63
15 Part number 87112000240, CLIP (10X) 18 AFTER FD992 CLIP (10X) 18 AFTER FD992
Worcester part no. 87112000240
£12.94
16 Part number 87174052870, NOW USE 87186673220 VALVE NOW USE 87186673220 VALVE
Worcester part no. 87174052870

16 Part number 87186673220, VALVE VALVE
Worcester part no. 87186673220
£49.16
17 Part number 87161094290, GAS COCK GAS COCK
Worcester part no. 87161094290
£17.38
18 Part number 87161156740, WASHER 23.9 X 17.2 X 1.5 (X1) BEFORE FD991 WASHER 23.9 X 17.2 X 1.5 (X1) BEFORE FD991
Worcester part no. 87161156740
£2.84
