VAILLANT
ECOTEC EXCLUSIVE 838 VUW 386/4 2007-2016 - (08 Connection Parts (Hydroblock))
Appliance Code: 47-044-38

Appliance Diagram


08 Connection Parts (Hydroblock) diagram for Vaillant Ecotec Exclusive 838 VUW 386/4 2007-2016Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020021013, Tube TUBE
Vaillant part no. 0020021013		 £21.29
2 Part number 080387, Tube, flexible TUBE, FLEXIBLE
Vaillant part no. 080387		 £12.57
4 Part number 0020021014, Tube TUBE
Vaillant part no. 0020021014		 £21.88
5 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £7.05
6 Part number 0020028056, NOW USE 0020131637 PUMP NOW USE 0020131637 PUMP
Vaillant part no. 0020028056
6 Part number 0020131637, PUMP PUMP
Vaillant part no. 0020131637		 £406.46
7   AUTOMATIC AIR VENT
Vaillant part no. 0010033857		 £18.87
7 Part number 104521, NOW USE 0010033857 automatic air vent NOW USE 0010033857 AUTOMATIC AIR VENT
Vaillant part no. 104521
8 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
9 Part number 981151, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981151		 £7.86
10 Part number 0020021015, Tube TUBE
Vaillant part no. 0020021015		 £21.73
11   TUBE
Vaillant part no. 0020021020		 £25.09
12 Part number 074517, Filter FILTER
Vaillant part no. 074517		 £11.55
13 Part number 0020028053, Tube TUBE
Vaillant part no. 0020028053		 £55.60
14 Part number 0020028054, Tube TUBE
Vaillant part no. 0020028054		 £55.60
15 Part number 252457, Diverter valve DIVERTER VALVE
Vaillant part no. 252457		 £139.42
17 Part number 0020022744, Valve VALVE
Vaillant part no. 0020022744		 £55.60
18 Part number 178980, bypass BYPASS
Vaillant part no. 178980		 £25.11
19 Part number 981165, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981165		 £6.69
20 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
21   TUBE
Vaillant part no. 0020028055		 £55.60
22 Part number 065132, Heat exchanger dhw (38 plates) HEAT EXCHANGER DHW (38 PLATES)
Vaillant part no. 065132		 £235.05
23 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
24 Part number 219622, Spring clamp (PK10) SPRING CLAMP (PK10)
Vaillant part no. 219622		 £9.49
25   TUBE
Vaillant part no. 0020021023		 £25.09
26 Part number 219636, Clip (PK2) CLIP (PK2)
Vaillant part no. 219636		 £7.05
28 Part number 178988, Flow sensor FLOW SENSOR
Vaillant part no. 178988		 £26.24
29 Part number 178966, clip CLIP
Vaillant part no. 178966		 £6.66
30 Part number 178992, Clip, (PK10) CLIP, (PK10)
Vaillant part no. 178992		 £8.18
31 Part number 0020021024, Connection CONNECTION
Vaillant part no. 0020021024		 £30.19
32 Part number 022640, Tube TUBE
Vaillant part no. 022640		 £29.58
33 Part number 0020022743, Limiter, high temperature 9.4l/min LIMITER, HIGH TEMPERATURE 9.4L/MIN
Vaillant part no. 0020022743		 £12.58
34 Part number 074514, Filter FILTER
Vaillant part no. 074514		 £6.66
35 Part number 0020022746, cable tree CABLE TREE
Vaillant part no. 0020022746		 £44.70
36 Part number 253595, NOW USE 0020059717 sensor, CH pressure NOW USE 0020059717 SENSOR, CH PRESSURE
Vaillant part no. 253595
36 Part number 0020059717, sensor (water pressure) SENSOR (WATER PRESSURE)
Vaillant part no. 0020059717		 £25.74
37 Part number 178993, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 178993		 £6.69
38 Part number 118951, Pan head screw, M6x28,5 PAN HEAD SCREW, M6X28,5
Vaillant part no. 118951		 £4.92
39 Part number 981234, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981234		 £7.05
40 Part number 193592, Sensor NTC (CH flow/CH return) SENSOR NTC (CH FLOW/CH RETURN)
Vaillant part no. 193592		 £9.67
41 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154		 £6.69
43 Part number 181051, Expansion vessel 10 ltr. EXPANSION VESSEL 10 LTR.
Vaillant part no. 181051		 £135.15
44 Part number 085751, NOW USE 0020107709 pressure gauge clip NOW USE 0020107709 PRESSURE GAUGE CLIP
Vaillant part no. 085751
44 Part number 0020107709, Support SUPPORT
Vaillant part no. 0020107709		 £6.66
45 Part number 180982, pressure Gauge PRESSURE GAUGE
Vaillant part no. 180982		 £17.94
46 Part number 981155, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981155		 £6.34
47 Part number 0020041891, Valve VALVE
Vaillant part no. 0020041891		 £52.06
48 Part number 981146, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981146		 £6.69
49 Part number 0020041892, Hose HOSE
Vaillant part no. 0020041892		 £15.62
50 Part number 981165, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981165		 £6.69
51 Part number 0020010294, Valve VALVE
Vaillant part no. 0020010294		 £20.56
52 Part number 0020010292, Handle, (PK2) HANDLE, (PK2)
Vaillant part no. 0020010292		 £7.05
53 Part number 103429, Sensor NTC, DHW outlet pipe SENSOR NTC, DHW OUTLET PIPE
Vaillant part no. 103429		 £8.63
54 Part number 103430, Sensor NTC, DHW heat exchanger SENSOR NTC, DHW HEAT EXCHANGER
Vaillant part no. 103430		 £8.71
55   TUBE
Vaillant part no. 0020021022		 £7.05
56 Part number 0020041893, Valve VALVE
Vaillant part no. 0020041893		 £34.31
57   NUT
Vaillant part no. 100004		 £6.66
