WORCESTER
GREENSTAR COMBI 35 CDI - (Control Box)
Appliance Code: 47-311-94

Appliance Diagram


Control Box diagram for Worcester Greenstar Combi 35 CDIClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 87172077470, CONTROL BOX HT3 BEFORE FD206 CONTROL BOX HT3 BEFORE FD206
Worcester part no. 87172077470		 £322.02
1 Part number 87377017930, NOW USE 8716119315 HEAT EXCHANGER BASIC BLOCK NOW USE 8716119315 HEAT EXCHANGER BASIC BLOCK
Worcester part no. 87377017930
1 Part number 8716119315, HEAT EXCHANGER BASIC BLOCK C/W SUMP HEAT EXCHANGER BASIC BLOCK C/W SUMP
Worcester part no. 8716119315		 £654.52
2 Part number 87133011960, NUT NUT
Worcester part no. 87133011960		 £1.19
2 Part number 87120001290, ROTARY HANDLE ROTARY HANDLE
Worcester part no. 87120001290		 £4.85
3 Part number 87110003020, COVER COVER
Worcester part no. 87110003020		 £14.90
3 Part number 87229638580, TEMPERATURE LIMITER BEFORE FD886 TEMPERATURE LIMITER BEFORE FD886
Worcester part no. 87229638580		 £30.48
4 Part number 87110002620, COVER COVER
Worcester part no. 87110002620		 £66.31
4 Part number 87172076800, COVER COVER
Worcester part no. 87172076800		 £4.15
5 Part number 87172076780, UPPER HOUSING UPPER HOUSING
Worcester part no. 87172076780		 £49.27
5 Part number 87101031530, SEALING SEALING
Worcester part no. 87101031530		 £9.51
6 Part number 87180038360, SHIELD SHIELD
Worcester part no. 87180038360		 £5.45
6 Part number 87144043480, SET OF CONNECTORS SET OF CONNECTORS
Worcester part no. 87144043480		 £11.92
7 Part number 87483005360, NOW USE 8748300912 Printed circuit NOW USE 8748300912 PRINTED CIRCUIT
Worcester part no. 87483005360
7 Part number 87181070890, NOW USE 8716121817 SET OF ELECTRODES NOW USE 8716121817 SET OF ELECTRODES
Worcester part no. 87181070890
7 Part number 8748300912, PRINTED CIRCUIT BOARD (BEFORE FD205 05/2012) PRINTED CIRCUIT BOARD (BEFORE FD205 05/2012)
Worcester part no. 8748300912		 £109.01
7 Part number 8716121817, SET OF ELECTRODES SET OF ELECTRODES
Worcester part no. 8716121817		 £49.58
7 Part number 87186643010, NOW USE 8716121817 SET OF ELECTRODES NOW USE 8716121817 SET OF ELECTRODES
Worcester part no. 87186643010
7 Part number 87483006430, NOW USE 8748300912 CIRCUIT BOARD - G NOW USE 8748300912 CIRCUIT BOARD - G
Worcester part no. 87483006430
8 Part number 87145000870, TEMPERATURE SENSOR TEMPERATURE SENSOR
Worcester part no. 87145000870		 £27.12
8 Part number 87172010520, TRANSFORMER TRANSFORMER
Worcester part no. 87172010520		 £22.71
9 Part number 87172076790, BACK PANEL BEFORE FD205 (05.2012) BACK PANEL BEFORE FD205 (05.2012)
Worcester part no. 87172076790		 £35.98
9 Part number 87180066580, BURNER BURNER
Worcester part no. 87180066580		 £261.76
10 Part number 87110041680, BURNER SEALING BURNER SEALING
Worcester part no. 87110041680		 £18.70
10   CODE PLUG 1001 (LPG)
Worcester part no. 87144310010		 £5.66
10 Part number 87144310000, CODE PLUG 1000 (NG) CODE PLUG 1000 (NG)
Worcester part no. 87144310000		 £3.36
11 Part number 87155066990, SHIELD SHIELD
Worcester part no. 87155066990		 £26.09
11 Part number 87103052970, FIXING BOLT FIXING BOLT
Worcester part no. 87103052970		 £10.85
12 Part number 87154069780, COVER COVER
Worcester part no. 87154069780		 £158.40
13 Part number 87155058830, BEARING PLATE BEARING PLATE
Worcester part no. 87155058830		 £12.41
13 Part number 87144113270, NOW USE 8716117968 FAN HARNESS NOW USE 8716117968 FAN HARNESS
Worcester part no. 87144113270
13 Part number 8716117968, CABLE FAN CONNECTOR ASSEMBLY CABLE FAN CONNECTOR ASSEMBLY
Worcester part no. 8716117968		 £10.17
14 Part number 87161067390, IGNITION LEAD IGNITION LEAD
Worcester part no. 87161067390		 £24.39
14 Part number 87144113260, NOW USE 87161067390 IGNITION LEAD NOW USE 87161067390 IGNITION LEAD
Worcester part no. 87144113260
14 Part number 87290001830, WASHER WASHER
Worcester part no. 87290001830		 £8.59
15 Part number 87161069800, GROUND CABLE GROUND CABLE
Worcester part no. 87161069800		 £0.94
16 Part number 87161073290, PUMP CABLE PUMP CABLE
Worcester part no. 87161073290		 £9.24
16 Part number 87101001900, CLIP (10X) CLIP (10X)
Worcester part no. 87101001900		 £2.84
17 Part number 87110042640, NOW USE 87186644020 GASKET ELECTRODE WASHER NOW USE 87186644020 GASKET ELECTRODE WASHER
Worcester part no. 87110042640
17 Part number 87144113280, HARNESS BEFORE FD788 HARNESS BEFORE FD788
Worcester part no. 87144113280		 £45.44
17 Part number 87186643010, NOW USE 8716121817 SET OF ELECTRODES NOW USE 8716121817 SET OF ELECTRODES
Worcester part no. 87186643010
17 Part number 87186644020, WASHER WASHER
Worcester part no. 87186644020		 £2.56
18 Part number 8716119319, FLUE GAS COLLECTOR FLUE GAS COLLECTOR
Worcester part no. 8716119319		 £26.86
18 Part number 87180069440, NOW USE 871619319 FLUE GAS COLLECTOR NOW USE 871619319 FLUE GAS COLLECTOR
Worcester part no. 87180069440
19 Part number 87101031550, WASHER WASHER
Worcester part no. 87101031550		 £5.68
20 Part number 87101032060, SET OF WASHERS SET OF WASHERS
Worcester part no. 87101032060		 £1.29
20 Part number 19045227400, FUSING ELEMENT T1,6A (10X) FUSING ELEMENT T1,6A (10X)
Worcester part no. 19045227400		 £8.50
20 Part number 19045227300, FUSING ELEMENT T0,5A (10X) FUSING ELEMENT T0,5A (10X)
Worcester part no. 19045227300		 £7.10
20 Part number 19045213420, FUSING ELEMENT T2,5A (10X) FUSING ELEMENT T2,5A (10X)
Worcester part no. 19045213420		 £21.29
22 Part number 87161156770, FUSING ELEMENT T2.5A FUSING ELEMENT T2.5A
Worcester part no. 87161156770		 £2.45
22 Part number 87105062670, TEMPERATURE LIMITER ASSY AFTER FD887 TEMPERATURE LIMITER ASSY AFTER FD887
Worcester part no. 87105062670		 £40.94
23 Part number 87182251760, CLIP CLIP
Worcester part no. 87182251760		 £1.83
99 Part number 87190010650, GAS CONVERSION KIT LPG TO NG GAS CONVERSION KIT LPG TO NG
Worcester part no. 87190010650		 £3.61
