WORCESTER
GREENSTAR COMBI 30 CDI - (Casing)
Appliance Code: 47-311-93

Appliance Diagram


Casing diagram for Worcester Greenstar Combi 30 CDIClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 87154014500, FRONT SHELL FRONT SHELL
Worcester part no. 87154014500		 £261.76
1 Part number 87172044530, NOW USE 8716118443 FAN NOW USE 8716118443 FAN
Worcester part no. 87172044530
1 Part number 87161160670, FAN BEFORE FD790 FAN BEFORE FD790
Worcester part no. 87161160670		 £185.99
1 Part number 8716118443, FAN After FD791 FAN AFTER FD791
Worcester part no. 8716118443		 £185.99
2 Part number 87161165050, COVER COVER
Worcester part no. 87161165050		 £52.84
2 Part number 87290001830, WASHER WASHER
Worcester part no. 87290001830		 £8.59
2 Part number 87155066940, NOW USE 87161165050 COVER NOW USE 87161165050 COVER
Worcester part no. 87155066940
3 Part number 87113048110, PLATE PLATE
Worcester part no. 87113048110		 £49.28
3 Part number 87228801750, O-RING (10X) O-RING (10X)
Worcester part no. 87228801750		 £11.98
4 Part number 87133060540, THROTTLE THROTTLE
Worcester part no. 87133060540		 £38.18
4 Part number 87180069460, PLATE PLATE
Worcester part no. 87180069460		 £3.20
5 Part number 87113022070, HINGE HINGE
Worcester part no. 87113022070		 £1.37
5 Part number 87105061610, PROTECTIVE CAP (10X) AFTER FD887 PROTECTIVE CAP (10X) AFTER FD887
Worcester part no. 87105061610		 £2.00
6 Part number 87123050920, LEAD SEAL LEAD SEAL
Worcester part no. 87123050920		 £1.37
6 Part number 87107352960, EXHAUST PIPE UNION EXHAUST PIPE UNION
Worcester part no. 87107352960		 £14.09
7 Part number 87110042320, WASHER 80MM WASHER 80MM
Worcester part no. 87110042320		 £10.03
8 Part number 87107352990, FLUE GAS DUCT FLUE GAS DUCT
Worcester part no. 87107352990		 £18.78
8 Part number 87107353660, NOW USE 87186630720 SUCTION PIPE NOW USE 87186630720 SUCTION PIPE
Worcester part no. 87107353660
8 Part number 87186630720, RESONATOR AIR INTAKE MK1.75 RESONATOR AIR INTAKE MK1.75
Worcester part no. 87186630720		 £13.84
9 Part number 87229333300, FLUE PIPE SEAL + 87,5MM FLUE PIPE SEAL + 87,5MM
Worcester part no. 87229333300		 £4.19
10 Part number 87134030260, SCREW M5X22 (10X) SCREW M5X22 (10X)
Worcester part no. 87134030260		 £3.78
10 Part number 87161156830, SCREW - OVAL-HEAD M5X22 (X1) SCREW - OVAL-HEAD M5X22 (X1)
Worcester part no. 87161156830		 £3.78
11 Part number 87154072960, NOW USE 8716122434 EXPANSION VESSEL 7L NOW USE 8716122434 EXPANSION VESSEL 7L
Worcester part no. 87154072960
11 Part number 87107353010, GAS PIPE GAS PIPE
Worcester part no. 87107353010		 £29.03
11   EXPANSION VESSEL
Worcester part no. 8716122434		 £92.23
12 Part number 87102051030, O-RING (10X) O-RING (10X)
Worcester part no. 87102051030		 £2.79
12 Part number 87101032090, WASHER WASHER
Worcester part no. 87101032090		 £2.47
13 Part number 87101030450, WASHER 18.6 X 13.5 X 1.5 (10X) WASHER 18.6 X 13.5 X 1.5 (10X)
Worcester part no. 87101030450		 £2.95
13 Part number 87101031610, WASHER 18,3X24,3 (10X) WASHER 18,3X24,3 (10X)
Worcester part no. 87101031610		 £8.27
14   CONNECTING PIPE
Worcester part no. 87107352980		 £3.13
14 Part number 87161068080, BADGE BADGE
Worcester part no. 87161068080		 £7.60
15 Part number 87154024720, FIXING SET FIXING SET
Worcester part no. 87154024720		 £41.80
16 Part number 87155035600, COVERING SHEET COVERING SHEET
Worcester part no. 87155035600		 £18.78
16 Part number 87155035600, COVERING SHEET COVERING SHEET
Worcester part no. 87155035600		 £18.78
16 Part number 87105061170, PROTECTIVE CAP PROTECTIVE CAP
Worcester part no. 87105061170		 £1.37
17   OBSOLETE LEAD SEAL
Worcester part no. 87123050230
17 Part number 87123050770, SECURITY TAG BLACK SECURITY TAG BLACK
Worcester part no. 87123050770		 £26.71
17 Part number 87123050770, SECURITY TAG BLACK SECURITY TAG BLACK
Worcester part no. 87123050770		 £26.71
18 Part number 87161120610, FAN MOUNTING PLATE ASSEMBLY FAN MOUNTING PLATE ASSEMBLY
Worcester part no. 87161120610		 £9.15
19   GAS SUPPLY PIPE
Worcester part no. 87107353070		 £41.80
20 Part number 87132040170, NOW USE 87161163220 RETAINING CATCH NOW USE 87161163220 RETAINING CATCH
Worcester part no. 87132040170
20 Part number 87161163220, RETAINING CATCH (1X) BEFORE FD987 RETAINING CATCH (1X) BEFORE FD987
Worcester part no. 87161163220		 £1.70
21 Part number 87161165150, GAS_VALVE SIT 848 GAS_VALVE SIT 848
Worcester part no. 87161165150		 £110.76
21 Part number 87182252430, CONVERSION KIT SIT 848 CONVERSION KIT SIT 848
Worcester part no. 87182252430		 £172.49
21 Part number 87161164280, PRESSURE GAUGE AFTER FD985 PRESSURE GAUGE AFTER FD985
Worcester part no. 87161164280		 £21.38
21 Part number 87182213470, NOW USE 87161165150 (dependent on serial no.) GAS VALVE SIT 848 NOW USE 87161165150 (DEPENDENT ON SERIAL NO.) GAS VALVE SIT 848
Worcester part no. 87182213470
22 Part number 87182210630, PRESSURE BALANCE TUBE PRESSURE BALANCE TUBE
Worcester part no. 87182210630		 £3.13
22 Part number 87182210630, PRESSURE BALANCE TUBE PRESSURE BALANCE TUBE
Worcester part no. 87182210630		 £3.13
23 Part number 87182223150, ADAPTER ADAPTER
Worcester part no. 87182223150		 £15.61
24 Part number 87182210620, ANGLE BRACKET SIT 848 ANGLE BRACKET SIT 848
Worcester part no. 87182210620		 £2.44
25 Part number 29106124240, SCREW NO8X3/8" PHILLIPS (10X) SCREW NO8X3/8" PHILLIPS (10X)
Worcester part no. 29106124240		 £0.59
26   GAS PIPE
Worcester part no. 87182210600		 £31.08
27 Part number 87182210590, GAS SUPPLY PIPE GAS SUPPLY PIPE
Worcester part no. 87182210590		 £37.68
